Cobot 20kg Payload 1400mm



GCR20‑1400 | 20kg Payload / 1400mm Reach Collaborative Robot

Product Overview

The GCR20‑1400 is a 6‑axis high‑performance collaborative robot designed and manufactured by DUCO Robots. It combines a 20kg payload with an extended 1400mm reach, making it ideal for medium‑to‑heavy handling, assembly, and inspection tasks across automotive, 3C, and general industry. With a slim, single‑tube arm structure, smooth motion, and full IP protection, it delivers KUKA‑level stability and precision in human‑robot collaborative environments.

Core Advantages

  • 20kg High Payload + 1400mm Long Reach

    Covers large work envelopes while handling heavy components, reducing cell footprint and improving line efficiency.

  • ±0.05mm Repeatability

    Consistent high precision for assembly, fitting, and quality inspection tasks.

  • Safe Human‑Robot Collaboration

    16 TUV‑certified safety functions (collision detection, force & power monitoring). No safety fence required; saves layout cost and floor space.

  • High Dynamic Performance

    Max TCP speed 2.2m/s, max linear speed 1.5m/s — fast cycle times without sacrificing accuracy.

  • Industrial‑Grade Protection

    IP54 (standard) / IP65 (wrist) — reliable operation in dusty, humid, or harsh workshop conditions.

  • Easy Integration & Programming

    Drag‑and‑drop teaching, support for TCP/IP, Modbus/TCP, Profinet, Ethernet/IP; compatible with vision systems and various end‑effectors.



Technical Specifications

Parameter GCR20‑1400
Model GCR20‑1400
Degrees of Freedom 6
Rated Payload 20 kg
Maximum Reach 1400 mm
Repeat Positioning Accuracy ±0.05 mm
Max TCP Speed 2.2 m/s
Max Linear Speed 1.5 m/s
Protection Class IP54 (body) / IP65 (wrist)
Communication TCP/IP, Modbus/TCP, Profinet, Ethernet/IP
Mounting Floor / Wall / Ceiling
Operating Temperature 0 °C ~ +45 °C
Weight ~75 kg



Applications

  • Automotive: glass assembly, heavy parts handling, wheel/door assembly, dispensing
  • 3C & Electronics: chassis assembly, module insertion, testing
  • General Industry: machine tending, palletizing, material handling, quality inspection
  • Logistics & Warehousing: box handling, loading/unloading

Design & Visual Style Minimalist industrial layout:

White/light‑gray body, clean lines, single‑tube arm
Multi‑angle product renders (front/side/reach view)
Technical infographics: reach diagram, payload curve, work envelope Emphasis on performance, safety, reliability (no over‑marketing language)
