Product Name: U-400 True 5-Axis Cradle Machining Center
Brand: NewRoad
Product Positioning: High-performance 5-axis linkage machine tool, specially developed for machining complex curved surfaces, irregular cavities and multi-angle workpieces. It integrates advanced DD direct-drive cradle rotary table, BBT direct-drive spindle and standard RTCP function, delivering outstanding precision, rigidity and processing efficiency for high-end manufacturing scenarios.
1. Product Overview
The U-400 true 5-axis cradle machining center is a high-end CNC machine tool designed for complex machining scenarios. Adopting professional double cradle structure and five-axis five-linkage technology, it effectively solves the machining difficulties of complex curved surfaces and special-shaped cavities, enabling one-time forming of irregular and multi-angle workpieces. Equipped with industry-leading core configurations, the machine realizes one-clamping and full-process forming, which greatly shortens production cycles and reduces fixture costs.
Engineered with high-rigidity machine body and precision transmission components, this model maintains stable performance during long-term continuous operation. With a maximum load capacity of 1.5 tons, it supports medium and heavy-duty precision machining. It is widely applied in aerospace, automobile, mold, engineering machinery, valve, shipbuilding and electronic industries, serving as a cost-effective alternative to imported high-end five-axis equipment.
2. Core Configuration & Technical Advantages
2.1 Double DD Direct-Drive Cradle Rotary Table
Built-in dual DD direct-drive cradle structure, eliminating traditional gear and belt transmission gaps. Features ultra-smooth rotation, fast response and zero backlash. It ensures high indexing accuracy and excellent dynamic performance during multi-angle linkage machining, fully adapting to frequent reversing and high-precision positioning requirements.
2.2 BBT Direct-Connect Mechanical Spindle
Adopts high-rigidity BBT direct-connect spindle design. Compared with traditional belt-driven spindles, it features higher rotational stability, stronger torque output and lower vibration. The structure effectively suppresses cutting vibration during heavy cutting and high-speed machining, protecting tool life and improving workpiece surface finish.
2.3 Standard RTCP Tool Center Point Follow Function
Comes with standard RTCP (Rotary Tool Center Point) follow function. The system can dynamically compensate the tool position in real time when the rotary axis moves, avoiding machining errors caused by rotary table offset. It guarantees consistent machining accuracy in full travel range and simplifies five-axis programming and debugging work significantly.
2.4 Overall Structural Strength
The whole machine body is cast with high-grade cast iron, after multiple stress relief treatments. The integral reinforcement structure improves overall rigidity and shock resistance, supporting 1.5-ton heavy-load stable machining. The machine will not deform under long-time heavy-load cutting, and the long-term accuracy retention is excellent.
3. Full Technical Parameter List
| Technical Item | Specification |
|---|---|
| Model | U-400 True 5-Axis Cradle Machining Center |
| Axis Configuration | 5-axis full linkage (3 linear axes + 2 rotary cradle axes) |
| Main Structure | Double DD Direct-Drive Cradle Rotary Table |
| Spindle Type | BBT Direct-Connect Mechanical Spindle |
| Standard Function | RTCP Tool Center Point Follow |
| Max Workpiece Load | 1500 kg (1.5 Tons) |
| Worktable Bearing Capacity | 1500 kg (1.5 Tons) |
| Indexing Accuracy | 8 arcseconds |
| Repeat Positioning Accuracy | ±0.003 mm |
| Main Application | Complex curved surfaces, special-shaped cavities, multi-angle precision parts |
| Continuous Operation | 24-hour non-stop stable heavy-load operation |
| Vibration Resistance | High anti-vibration design for 1.5-ton heavy cutting |
4. Application Industries & Typical Workpieces
This five-axis machining center provides complete cutting solutions for multiple high-end manufacturing fields, adapting to precision machining of workpieces within 1.5 tons:
- Aerospace Industry: Structural parts, thin-wall parts, complex cavity components for aviation and aerospace equipment.
- Automotive Industry: Auto mold core, fixture, new energy vehicle precision structural parts.
- Mold Industry: 3D complex surface molds, precision injection molds, die-casting molds.
- General Precision Machinery: Irregular parts, multi-angle assembly parts, medium-sized complex workpieces.
- Valve & Shipbuilding Industry: Special-shaped valve parts, ship auxiliary precision components.
5. Product Strength & Competitive Edges
- High Precision & Stability Indexing accuracy up to 8 arcseconds, matched with RTCP dynamic compensation technology. The whole machine maintains stable precision after long-term operation, meeting strict tolerance requirements of high-precision parts.
- High Machining Efficiency One clamping completes milling, drilling, boring, tapping and multi-angle processing. It reduces repeated clamping errors and greatly improves overall production efficiency.
- Superior 1.5-Ton Load Capacity & Rigidity Supports maximum 1.5-ton workpiece load. Reinforced cast iron body and direct-drive structure perfectly balance high-speed precision cutting and medium-heavy load cutting, with ultra-wide processing adaptability.
- Easy Operation & Low Maintenance Standard five-axis system with friendly operation interface. Mature modular components reduce daily maintenance difficulty and after-sales cost.
- Cost Performance Comparable performance with imported five-axis machine tools, while with more competitive price, shorter delivery cycle and localized after-sales support.
6. Complete Service Support
- Pre-sales Service: Professional process analysis, workpiece machining scheme customization, equipment selection guidance.
- After-sales Service: On-site installation, commissioning and operator training. 24-hour professional technical support nationwide.
- Warranty Policy: Standard warranty for the whole machine; long-term spare parts supply and lifetime technical maintenance.
- Extended Service: Support automated production line docking, personalized function customization and factory intelligent transformation solutions.
7. Inquiry & Contact
For detailed drawings, complete parameter manual, official quotation, delivery time and customized solutions, please contact our sales team.
